18650 4S2P 3000mAh is suitable for instrumentation, monitoring and detection

Product Number: 18650 4S2P 3000mAh

Nominal Voltage: 14.8V

Nominal Capacity: 3000mAh

Product Size: MAX 36*68*74mm

Charging Temperature: 0--45℃

Discharge Temperature: -20--60℃

Storage Temperature:-15--45℃

Application Field: instrumentation, monitoring and detection


detail
Product Number 18650 4S2P 3000mAh
Cell Model INR18650
Battery Specification INR18650 3.7V 1500mAh
Nominal Voltage 14.8V
Nominal Capacity 3000mAh
Charging Voltage 16.8V
Charging Current ≤2A
Discharge Current 6A
Instantaneous Discharge Current 10A
Discharge Cut-off Voltage 11V
Internal Resistance of Finished Product ≤250mΩ
Battery Weight 0.6KG
Product Size MAX 36*68*74mm
Charging Temperature 0--45℃
Discharge Temperature -20--60℃
Storage Temperature -15--45℃
Battery Housing Steel Shell PVC protective film
Intelligent Lithium Battery Protection Power management (RS485, CAN protocol), short circuit protection, overcharge protection, over discharge protection, over current protection, over temperature protection, etc.
Application Field instrumentation, monitoring and detection
Product advantages
  • Different Size: Type and Capacity are selectable Easy matching-up
  • Quality Assurance: Paili apply A-class cell, with high capacity and low inner-resistance
  • Stable Performance: Long life of cycles, capacity kept 80% of rated, after 500 cycles of charing-and-discharging
  • Free Memory-Sideeffectiveness: Charging, discharing and using is applicable any where, any time
  • High Safety: Protective design applied via inner PCB. No fire or explosion even Short, Over-charging, Over-discharging, Shock, Vibration, Puncture, High-temperature occured
