detail
Product Number | PL USB 10000A | ![]() |
|
Cell Model | USB PB | ||
Battery Specification | 10000mAh | ||
Nominal Voltage | 5V | ||
Nominal Capacity | 10000mAh | ||
Charging Voltage | 5V | ||
Charging Current | ≤2A | ||
Discharge Current | 2A | ||
Instantaneous Discharge Current | 2.4A | ||
Discharge Cut-off Voltage | 2.75V | ||
Internal Resistance of Finished Product | ≤160mΩ | ||
Battery Weight | ≤1kg | ||
Product Size | MAX 22*75*160mm | 翻译>||
Charging Temperature | 0~45℃ | ||
Discharge Temperature | -20~60℃ | ||
Storage Temperature | -20~45℃ | ||
Battery Housing | PP silico gel,Flame retardant plastic | ||
Intelligent Lithium Battery Protection | Over discharge, over charge, over current, over heat, short circuit, balance, communication | ||
Application Field | Solar USB Charger Mobile Phone Battery Pack Power Bank |
Product advantages
- Different Size: Type and Capacity are selectable Easy matching-up
- Quality Assurance: Paili apply A-class cell, with high capacity and low inner-resistance
- Stable Performance: Long life of cycles, capacity kept 80% of rated, after 500 cycles of charing-and-discharging
- Free Memory-Sideeffectiveness: Charging, discharing and using is applicable any where, any time
- High Safety: Protective design applied via inner PCB. No fire or explosion even Short, Over-charging, Over-discharging, Shock, Vibration, Puncture, High-temperature occured
