Wide temperature polymer lithium battery

Product Number: 9759158 Wide temperature polymer lithium battery

Nominal Voltage: 3.7V

Nominal Capacity: 10000mAh

Product Size: 97*58*158

Charging Temperature: 0~45℃

Discharge Temperature: -20~60℃

Storage Temperature:-20~45℃

Application Field: Special equipment power supply, high and low temperature environment power supply


detail
Product Number 9759158 Wide temperature polymer lithium battery
Cell Model 9759158
Battery Specification 9759158
Nominal Voltage 3.7V
Nominal Capacity 10000mAh
Charging Voltage 4.2V
Charging Current ≤1A
Discharge Current 1A
Instantaneous Discharge Current 3A
Discharge Cut-off Voltage 2.75V
Internal Resistance of Finished Product ≤100mΩ
Battery Weight ≤1kg
Product Size 97*58*158
Charging Temperature 0~45℃
Discharge Temperature -20~60℃
Storage Temperature -20~45℃
Battery Housing Steel Shell
Intelligent Lithium Battery Protection Power management (RS485, CAN protocol), short circuit protection, overcharge protection, over discharge protection, over current protection, over temperature protection, etc.
Application Field Special equipment power supply, high and low temperature environment power supply

Special equipment power supply, high and low temperature environment power supply

Product advantages
  • Different Size: Type and Capacity are selectable Easy matching-up
  • Quality Assurance: Paili apply A-class cell, with high capacity and low inner-resistance
  • Stable Performance: Long life of cycles, capacity kept 80% of rated, after 500 cycles of charing-and-discharging
  • Free Memory-Sideeffectiveness: Charging, discharing and using is applicable any where, any time
  • High Safety: Protective design applied via inner PCB. No fire or explosion even Short, Over-charging, Over-discharging, Shock, Vibration, Puncture, High-temperature occured
